  • 50㎡ square circular vacuum freeze dryer

    Instructions: Supply water and electricity→Raw materials loading the tray→Put into Frozen storage →After Freezing turn to the cabin and sublimation drying → Finished and packaging

    Capacity:500KG-3000KG

    Equipment model:BLK-FD-50(50㎡)、BLK-FD-100(100㎡)、BLK-FD-150(150㎡)、BLK-FD-200(200㎡)

    Applications: Vegetables, Fruits (apples, strawberries, kiwifruit, bananas, durian, carambola, balsam, etc.), Flowers (roses, etc.), Medicinal materials (cordyceps, medlar, dendrobium, antler, ginseng, etc.), Liquid products (probiotics, honey, laboratory syntheses, etc.),Bbiological products, Chemical raw materials, etc. Other types of products freeze dry please consult!


    • ¥0.00
      ¥0.00
      ¥0.00
      ¥0.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:0.000KG
    • Quantity:
Description

Instructions: Supply water and electricity→Raw materials loading the tray→Put into Frozen storage →After Freezing turn to the cabin and sublimation drying → Finished and packaging

Capacity:500KG-3000KG

Equipment model:BLK-FD-50(50㎡)、BLK-FD-100(100㎡)、BLK-FD-150(150㎡)、BLK-FD-200(200㎡)

Applications: Vegetables, Fruits (apples, strawberries, kiwifruit, bananas, durian, carambola, balsam, etc.), Flowers (roses, etc.), Medicinal materials (cordyceps, medlar, dendrobium, antler, ginseng, etc.), Liquid products (probiotics, honey, laboratory syntheses, etc.),Bbiological products, Chemical raw materials, etc. Other types of products freeze dry please consult!



Model

BLK-FD-50

BLK-FD-100

BLK-FD-150

BLK-FD-200

Overall appearance and size (m)

Round diameter 2.4*7

Square 7.5*2.1*2.5

Round diameter 2.4*10.5

Square  11.3*2.1*2.5

Round diameter 2.4*14.5

Square 14.5*2.1*2.5

Round diameter 2.4*18.6

Square  18.8*2.1*2.5

Installed power

84KW

158KW

236KW

293KW

Effective area of pallet

50.5m²

101.1m²

151.6m²

202.2m²

Cold trap temperature



-30-45



-30-45



-30-45



-30-45

Ultimate vacuum

1Pax15Pa

1Pax15Pa

1Pax15Pa

1Pax15Pa

Heating method

Electric heating or steam heating

Electric heating or steam heating

Electric heating or  steam heating

Electric heating or steam heating

General charging capacity

500KG

1000KG

1500KG

2000-3000KG

Note: Except for the above models, all vacuum freeze dryers with 5KG-3000KG processing capacity can be produced according to customer requirements.
