Instructions: Supply water and electricity→Raw materials loading the tray→Put into freeze-dryer→Freezing and sublimation drying (freeze-dryer can be directly pre-freezing) → Finished and packaging
Capacity:50KG-300KG
Equipment model:BLK-FD-5(5㎡),BLK-FD-10(10㎡),BLK-FD-20(20㎡),BLK-FD-30(30㎡)
Applications: Vegetables, Fruits (apples, strawberries, kiwifruit, bananas, durian, carambola, balsam, etc.), Flowers (roses, etc.), Medicinal materials (cordyceps, medlar, dendrobium, antler, ginseng, etc.), Liquid products (probiotics, honey, laboratory syntheses, etc.),Bbiological products, Chemical raw materials, etc. Other types of products freeze dry please consult!
Model | BLK-FD-5 | BLK-FD-10 | BLK-FD-20 | BLK-FD-30 |
Overall appearance and size (mm) | Square 3500*1800*2300 | Square 4700*1800*2300 | Square 5200*1800*3000 | Square 6700*1800*3000 |
Installed power | 15.9KW | 20.9KW | 39.2KW | 52.5KW |
Effective area of pallet | 5.005m² | 10.1m² | 20.02m² | 30.03m² |
Clapboard temperature | -45℃~+80℃ | -45℃~+80℃ | -45℃~+80℃ | -45℃~+80℃ |
Cold trap temperature | Minimum negative 50 ℃ | Minimum negative 50 ℃ | Minimum negative 50 ℃ | Minimum negative 50 ℃ |
Ultimate vacuum | 10Pa (empty container) | 10Pa (empty container) | 10Pa (empty container) | 10Pa (empty container) |
Heating method | Silicone oil, electric heating(6KW) | Silicone oil, electric heating(10KW) | Silicone oil, electric heating(20KW) | Silicone oil, electric heating(30KW) |
General charging capacity | 50KG | 100KG | 200KG | 300KG |
Note: Except for the above models, all vacuum freeze dryers with 5KG-3000KG processing capacity can be produced according to customer requirements.
