Instructions: Supply water and electricity→Raw materials loading the tray→Put into Frozen storage→After Freezing turn to the cabin and sublimation drying→ Finished and packaging
Capacity:500KG-3000KG
Equipment model:BLK-FD-50(50㎡),BLK-FD-100(100㎡),BLK-FD-150(150㎡),BLK-FD-200(200㎡)
Applications: Vegetables, Fruits (apples, strawberries, kiwifruit, bananas, durian, carambola, balsam, etc.), Flowers (roses, etc.), Medicinal materials (cordyceps, medlar, dendrobium, antler, ginseng, etc.), Liquid products (probiotics, honey, laboratory syntheses, etc.),Bbiological products, Chemical raw materials, etc. Other types of products freeze dry please consult!
Model | BLK-FD-50 | BLK-FD-100 | BLK-FD-150 | BLK-FD-200 |
Overall appearance and size (m) | Round diameter 2.4*7 Square 7.5*2.1*2.5 | Round diameter 2.4*10.5 Square 11.3*2.1*2.5 | Round diameter 2.4*14.5 Square 14.5*2.1*2.5 | Round diameter 2.4*18.6 Square 18.8*2.1*2.5 |
Installed power | 84KW | 158KW | 236KW | 293KW |
Effective area of pallet | 50.5m² | 101.1m² | 151.6m² | 202.2m² |
Cold trap temperature |
-30℃~-45℃ |
-30℃~-45℃ |
-30℃~-45℃ |
-30℃~-45℃ |
Ultimate vacuum | 1Pa≤x≤15Pa | 1Pa≤x≤15Pa | 1Pa≤x≤15Pa | 1Pa≤x≤15Pa |
Heating method | Electric heating or steam heating | Electric heating or steam heating | Electric heating or steam heating | Electric heating or steam heating |
General charging capacity | 500KG | 1000KG | 1500KG | 2000-3000KG |
Note: Except for the above models, all vacuum freeze dryers with 5KG-3000KG processing capacity can be produced according to customer requirements.
