  • 1㎡ square experimental freeze dryer

    Instructions: Supply water and electricity→Raw materials loading the tray→Put into freeze-dryer→Freezing and sublimation drying (freeze-dryer can be directly pre-freezing) → Finished and packaging

    Capacity:5KG-20KG

    Equipment model:BLK-FD-0.5(0.5㎡)、BLK-FD-1(1㎡)、BLK-FD-2(2㎡)

    Applications: Vegetables, Fruits (apples, strawberries, kiwifruit, bananas, durian, carambola, balsam, etc.), Flowers (roses, etc.), Medicinal materials (cordyceps, medlar, dendrobium, antler, ginseng, etc.), Liquid products (probiotics, honey, laboratory syntheses, etc.),Bbiological products, Chemical raw materials, etc. Other types of products freeze dry please consult!



    • ¥0.00
      ¥0.00
      ¥0.00
      ¥0.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:0.000KG
    • Quantity:
    • Consultation
Description

Instructions: Supply water and electricity→Raw materials loading the tray→Put into freeze-dryer→Freezing and sublimation drying (freeze-dryer can be directly pre-freezing) → Finished and packaging

Capacity:5KG-20KG

Equipment model:BLK-FD-0.5(0.5㎡)、BLK-FD-1(1㎡)、BLK-FD-2(2㎡)

Applications: Vegetables, Fruits (apples, strawberries, kiwifruit, bananas, durian, carambola, balsam, etc.), Flowers (roses, etc.), Medicinal materials (cordyceps, medlar, dendrobium, antler, ginseng, etc.), Liquid products (probiotics, honey, laboratory syntheses, etc.),Bbiological products, Chemical raw materials, etc. Other types of products freeze dry please consult!




Model

BLK-FD-0.5

BLK-FD-1

BLK-FD-2

Overall appearance and size mm

Square

1200*900*1500

Square

1500*1000*1700

Square

1800*1000*2000

Installed power

4.9KW

5.9KW

7KW

Effective area of pallet

0.5m²

1.07m²

2.14m²

Clapboard temperature

-45~+80

-45~+80

-45~+80

Cold trap temperature

Minimum negative 50 ℃

Minimum negative 50 ℃

Minimum negative 50 ℃

Ultimate vacuum

≤10Pa

empty container

≤10Pa

empty container

≤10Pa

empty container

Heating   method

Silicone oil, electric heating2KW

Silicone oil, electric heating2KW

Silicone oil, electric heating2KW

General charging capacity

5KG

10KG

20KG

Note: Except for the above models, all vacuum freeze dryers with 5KG-3000KG processing capacity can be produced according to customer requirements.
